Work speed and versatility in up to 3 axis
The new STS CNC lathe series is versatile, fast and accurate, developed under the robust quality standards of the JAP premium technology. The new JAP beds provides increased rigidity improving the dimensional and thermal stability of the machine and reduces the level of vibration during the machining process.
The STS series has a headstock equipped with a belt-drive servomotor and a high quality and low run-out main spindle, providing a lathe with high spindle speed, reduced noise level and high quality surface finish capability. The JAP STS are lathes with up to 3 axes that provide extraordinary versatility in the world of machine tools.
STANDARD EQUIPMENT
OPTIONAL EXTRAS
- Fanuc Oi-TF Control
- Dynamic graphics / trajectory
- Profile Editor
- Electronic handwheel for X and Z axes
- Increased width and stiffness of the bed
- Direct drive headstock with servomotor
- High precision main spindle
- Reducing bush of main shaft and dead centers
- 8-position automatic turret
- Automatic lubrication of the guideways
- Refrigeration equipment
- Cast iron pedestals
- Precision Levellers
- LED Work light
- Instruction manual
- Verification standard DIN 8605
- CE Standard
- Control Fagor 8055i, Siemens 828D, Fagor 8058 or Fagor 8060
- C-axis*
- Chucks with 3 and 4 jaws
- Rear chuck
- Hydraulic power chuck
- Hydraulic collect chuck
- Hydraulic tailstock
- Fixed Steady Rest
- Large capacity fixed steady rest
- Follow Rest
- Livetool 12 positions
- Live center
- Chip conveyor
- Electric transformer
- Higher pressure cooling system
- Electric panel refrigeration
- Anti-vibration kit
- Remote jog unit
- Tool Presetter
- Bar feeder
*Note: Not available for STS200
STANDARD EQUIPMENT
- Fanuc Oi-TF Control
- Dynamic graphics / trajectory
- Profile Editor
- Electronic handwheel for X and Z axes
- Increased width and stiffness of the bed
- Direct drive headstock with servomotor
- High precision main spindle
- Reducing bush of main shaft and dead centers
- 8-position automatic turret with 4 toolholders
- Automatic lubrication of the guideways
- Refrigeration equipment
- Cast iron pedestals
- Precision Levellers
- LED Work light
- Instruction manual
- Verification standard DIN 8605
- CE Standard
OPTIONAL EXTRAS
- Control Fagor 8055T, Siemens 828D
- C-axis
- Chucks with 3 and 4 jaws
- Rear chuck
- Hydraulic power chuck
- Hydraulic collect chuck
- Hydraulic tailstock
- Fixed Steady Rest
- Large capacity fixed steady rest
- Follow Rest
- Livetool 12 positions
- Live center
- Chip conveyor
- Electric transformer
- Higher pressure cooling system
- Electric panel refrigeration
- Anti-vibration kit
- Remote jog unit
- Tool Presetter
- Bar feeder
CNC LATHES High-Precision Technology
