Large roughing CNC lathes with up to 4 axes
The STH series of CNC lathes marks a milestone among flatbed numerical control machines. STH are parallel lathes with up to 4 axes that have a reputation for versatility within their segment without loss of precision and quality of surface finish that have made STH a reference in the world of machine tools.
The headstock of the STH series is equipped with a 2-step gear box providing a high output in the roughing operation. In addition, the high quality and reduced run-out main spindle of the JAP machines, makes the STH the best friend of the most complex works.
STH parallel lathes have been designed with our most demanding customers in mind, using the highest quality components combined with the most innovative technology, the result of more than 75 years of experience.
Models with up to 4 CNC axes, 1050 mm turning on over bed and 5000 mm between centres.
STANDARD EQUIPMENT
OPTIONAL EXTRAS
- Fanuc 0i-TF
- Dynamic graphics / trajectory
- Profile Editor
- Screen 15”
- High precision main spindle
- Reducing bush of main shaft and dead centres
- Servomotor
- Gearbox 2 ranges
- 8-position automatic turret
- Remote jog unit
- Refrigeration equipment
- Cast iron pedestals
- Precision Levellers
- LED Work light
- Status signal light
- Instruction manual
- Verification standard DIN 8605
- CE Standard
- Fanuc Fagor 8060i, Siemens 828D
- Boring bar up to 310 mm
- High accuracy C-axis
- Y-axis
- Automatic and live tool 8 or 12 positions VDI or BMT
- Chucks with 3 and 4 jaws
- Hydraulic chuck and tailstock
- Fixed steady rests of various capacities
- Follow Rest
- Hydraulic Steady Rest
- Electric transformer
- Rear chuck
- Support for boring bars
- Live center
- Higher pressure coolant pump
- Chip conveyor
- Linear capitation scales
- Anti-vibration kit
- Tool Presetter
- Electric panel cooler
STANDARD EQUIPMENT
- Fanuc 0i-TF
- Dynamic graphics / trajectory
- Profile Editor
- Screen 15”
- High precision main spindle
- Reducing bush of main shaft and dead centres
- Servomotor
- Gearbox 2 ranges
- 8-position automatic turret with 4 toolholders
- Remote jog unit
- Refrigeration equipment
- Cast iron pedestals
- Precision Levellers
- LED Work light
- Status signal light
- Instruction manual
- Verification standard DIN 8605
- CE Standard
OPTIONAL EXTRAS
- Fanuc Fagor 8060T, Siemens 828D
- Boring bar up to 360 mm
- High accuracy C-axis
- Y-axis
- Automatic and live tool 8 or 12 positions VDI or BMT
- Chucks with 3 and 4 jaws
- Hydraulic chuck and tailstock
- Fixed steady rests of various capacities
- Follow Rest
- Hydraulic Steady Rest
- Electric transformer
- Rear chuck
- Support for boring bars
- Live center
- Higher pressure coolant pump
- Chip conveyor
- Linear capitation scales
- Anti-vibration kit
- Tool Presetter
- Electric panel cooler
